The woofer is generally the largest driver in the system which covers the bass and mid-range frequency.

The SubBass Activator is an electrical circuit which extends the deepest bass when the music calls for it, reduces the distortion for cleaner sound, increases the dynamic range for greater impact, and uses a self-resetting protection circuit to reduce the chance of damaging the speakers.

The grill is the cloth and frame used to cosmetically conceal the drivers without affecting the sound. Ohm now uses black grills in almost all cases. In the past, brown and brown/black mixes were used; but every ”brown” turned out differently. Now they are all black.

The crossover is the electrical circuit that protects the tweeters from the low frequency energy that is reproduced by the main drivers. This can only fail, in rare instances, from overdriving the speakers.

The passive radiator looks like a large woofer from the outside. It produces the deepest octave of sound and has no magnet or motor assembly. The air inside the cabinet acts like a spring with the woofer driving one end and the passive radiator (PR) at the other. At the low frequency where the spring and the PR resonate, extra energy comes out of the system. Typically, the foam edge deteriorates within 20 years. We now use a new foam edge that is projected to last up to 30 years.

The tweeter is the high frequency element in the top corner of the box. When properly placed for full room stereo, these should be on the front corner closer to the other speaker, and they should cross fire in front of your listening position.

We need the original one back so we can install the new one in the triangular mounting board.
